Luxonis OAK-FFC-IMX378 12MP Color Rolling Shutter Camera Module
Offers 30 pin interface to the IMX378 camera module
Features 26 pin 0.5mm FFC interconnect to baseboard
Provides 5V power input via FFC
Onboard power generation for camera module
Compatible with the DepthAI RPi HAT and OAK-FFC-3P-OG baseboards
The Luxonis OAK-FFC-IMX378 12MP Color Rolling Shutter Camera Module is a carrier board for the Sunny A12N02A IMX378 camera module and is designed to be compatible with the DepthAI RPi HAT Baseboard and OAK-FFC-3P-OG baseboards.
A 26-pin FFC is used to carry 5V power, 4-lane MIPI, I2C, and other control signals between the OAK-FFC-OV9282 and the controller baseboards.
The FFC connector is an 0.5mm pitch, 26-pin, and bottom-contact, across which travels the 4-lane MIPI, 5V, I2C, camera clock, camera reset, and other optional control lines. 5V power is regulated down and filtered as appropriate to meet the requirements of the compact camera module and IMX378.
1x Luxonis OAK-FFC-IMX378 12MP Color Rolling Shutter Camera Module
Size
25 x 23.86 mm (L x W)
26 pin 0.5mm FFC interconnect to baseboard
30 pin interface to the IMX378 camera module
4-lane MIPI
Aux/Control signals to the camera module
5V power input via FFC
On-board power generation for camera module
Used with OAK-FFC-3P and DepthAI: RPi HAT
